Hikvision DS-7104HGHI-M1 4-Channel TurboHD DVR – Compact Security Solution

Professional Surveillance for Homes & Small Businesses

The Hikvision DS-7104HGHI-M1 is a compact 4-channel TurboHD DVR that delivers 5MP high-definition video over existing coax cabling. This energy-efficient recorder features H.265+ compression technology and smart motion detection in a space-saving design.

Key Features:

✔ 4-Channel Hybrid Input – Supports 5MP TurboHD (HDTVI), AHD, CVI, and analog cameras
✔ 5MP Ultra HD Resolution (2560×1920) – 3× sharper than standard 720p analog systems
✔ Advanced H.265+/H.265 Compression – Reduces storage needs by up to 80% vs. H.264
✔ 1 SATA HDD Bay – Supports up to 6TB storage (hard drive not included)
✔ Smart Motion Detection – Configurable zones with adjustable sensitivity
✔ 4K HDMI Output (3840×2160) – Ultra-clear local monitoring
✔ Hik-Connect Remote Access – View live/recorded footage via iOS/Android app
✔ Fanless Operation – Silent performance ideal for quiet environments

Technical Specifications:

• Video Input: 4× BNC (Analog/Hybrid)

• Max Resolution: 5MP (2560×1920)

• Compression: H.265+/H.265/H.264+

• Video Output: 4K HDMI, VGA (1920×1080)

• Storage: 1× SATA HDD (up to 6TB)

• Network: 1× RJ45 10/100Mbps

• Power: 12V DC, ≤10W

Ideal For:

• Small retail stores

• Home security systems

• Office reception areas

• Cost-effective upgrades from legacy analog systems

Why Choose This DVR?

• Maintain existing coax infrastructure while upgrading to HD

• Compact 1U form factor saves installation space

• Enterprise-grade reliability from Hikvision

• Energy-efficient operation (under 10W power consumption)

Package Includes:

• DVR main unit

• Power adapter

• Mouse

• Quick start guide
